DSD Multi-Display System

Introducing the DSD flex – your versatile system for event announcements, warnings, current information, and of course, reliable speed display! Configure the display conveniently from your computer – choose times, graphics, colours, and texts according to your individual preferences.

Features

  • FREELY CONFIGURABLE TEXT
  • GROWING LOGO DATABASE
  • MULTICOLOUR DISPLAY AND TEXT
  • RANGE UP TO 200 M
  • DISPLAY FROM 3 KM/H
  • EASY TO INSTALL
  • IMPACT AND WEATHER RESISTANT

With state-of-the-art sensor technology that responds from speeds as low as 3 km/h, the DSD flex is even suitable for pedestrian zones. No matter what application you envision – the DSD flex is the solution!

Robust design
The extremely lightweight and slim housings of DSD radar speed displays are temperature and weather resistant, globally deployed, and crafted from Luran® polymers for exceptional durability and impact resistance.

High-power LEDs
With a display height of 57 cm and perfectly focussed high-power LEDs, our system ensures optimum visibility, targeted at traffic to protect the environment.

Your location, your design!
We can place your city or company logo, photo, sponsorship message, or city skyline on your DSD flex.

Speed indicator and information display - The DSD flex

Applications

  • SPEED DISPLAY
  • EVENT ANNOUNCEMENT
  • PARADES & MARKETS
  • SPORTS EVENT INFORMATION
  • ENVIRONMENTAL REMINDERS
  • WORK SAFETY INFORMATION
  • INDUSTRIAL TRAFFIC RULES
  • JOB OFFER DISPLAY
  • BLOOD DONATION CALL
  • ICINESS WARNING
  • FLOOD WARNING
  • PARKING INFORMATION
  • SPECIAL EVENT
  • SKI LIFT NEW SNOW INDICATION
  • AND MUCH MORE...

High output LEDHigh output LED. 8 colours can be displayed
(white, black, red, green, blue, yellow, magenta, cyan)
Sensor typeMicrowave
FrequencyTyp. 24, 125 GHz
Output power5 mW
Radar rangeMin. 80 m; typ. 100 m; max. 200 m / min 260 ft; typ. 330 ft.; max. 656 ft
Speed measuring range3 - 255 km/h or 2 - 158 mph
Speed display range3 - 99 km/h or 2 - 62 mph
Resolution1 km/h or 1 mph
 UnitsMetric or Imperial
MemorySufficient for approx. 100 years of data acquisition (with 10K objects / day)
Data formatV entry, V exit, direction of travel, date, time (PVR) (Single vehicle registration)
Communication4G/LTE
Settingvia 4G/LTE
Installation angleHorizontal 0 - 5°; vertical 0°
Ambient temperature- 20 °C - + 50 °C / - 4 °F - + 122 °F
WeightDSD flex ca. 8 Kg / 17,64 lb
Dimensions (WxHxD)527 x 806 x 51 mm / 1’ 9” x 2’ 8” x 0’ 2” ft
Housing materialLuran ASA

Software

myTrafficDataWeb-based application, reporting and data management software

Energy supply

PowerUnit 33100 - 240 VAC main power supply incl. 12 V /  33 Ah rechargeable battery
Power supply unit12 VAC 100 – 240 (permanent power)

Installation

SmartBracket flatVariable pole mounting installation bracket for 40 to 160 mm diameter
SmartBracket deepVariable pole mounting installation bracket will carry a Powerpack or PowerUnit

Example configuration, as a speed display

Configuration examples for the message board/information

Online Configuration and Monitoring

What is the traffic situation at a given time? How much have speeds reduced? Configure DSD flex and generate reports
on myTrafficData

Learn more
